Bronze Ejector

Name: Bronze Ejector
Brand: Metroend

Product code pending

Bağlantı DIN1092-2

Çalışma basıncı PN16

Get a quote on WhatsApp Download catalog

site.urun_kaynak
Metroend-Urun-Katalogu.pdf · site.urun_basili_sayfa 109 (PDF 108)

What it does

Marine Equipment

Marine equipment covers the fittings used in the fuel, bilge, ballast, cooling and fire-fighting circuits of vessels and shore facilities. Saltwater corrosion, continuous vibration and limited maintenance opportunity are decisive for these products, and the material and sealing selection is made accordingly. In applications requiring classification society approval, the product must be supplied together with the relevant certificate.

This is a general description of the product type; it has no counterpart in the source catalog and is awaiting company approval. The verified technical values for this product are only in the data plate above and in the dimension table.

Where it is used

Application areas

01 Maritime Applications

Source: the “Application Areas” list on this product's catalog page.

site.urun_olculer

site.urun_olcu_tablosu

8 site.urun_satir × 20 site.urun_kolon

Bronze Ejector — site.urun_olcu_tablosu
kolon_1 *	(BASINÇ) DN	kolon_3 *	kolon_4 *	kolon_5 *	kolon_6 *	(BASINÇ) DN	kolon_8 *	kolon_9 *	kolon_10 *	kolon_11 *	(EMİŞ) DN	kolon_13 *	kolon_14 *	kolon_15 *	kolon_16 *	(ÇIKIŞ) L1	L2	L	KG
1 1/2" x 2"x 2 1/2"	40	150	110	88	18x4	50	165	125	108	18x4	65	185	145	122	18x4	115	115	580	16
2 1/2" x 2 1/2" x 3"	65	185	145	122	18x4	65	185	145	122	18x4	80	200	160	138	18x8	115	135	730	32
2" x 3" x 3"	50	165	125	102	18x4	80	200	160	138	18x8	80	200	160	138	18x8	115	135	678	32
3" x 4" x 4"	80	200	160	138	18x8	100	220	180	158	18x8	100	220	180	158	18x8	125	142,5	960	48
3" x 3" x 4"	80	200	160	138	18x8	80	200	160	138	18x8	100	220	180	158	18x8	117	142,5	960	46
4" x 5" x 5"	100	220	180	158	18x8	125	250	210	188	18x8	125	250	210	188	18x8	125	165	1070	60
4" x 4" x 5"	100	220	180	158	18x8	100	220	180	158	18x8	125	250	210	188	18x8	125	168	1055	58
5" x 6" x 6"	125	250	210	188	18x8	150	285	240	212	22x8	150	285	240	212	22x8	130	200	1330	85

* site.urun_kolon_notu

site.urun_malzeme

site.urun_malzeme_ozellikleri

site.urun_mat_no	site.urun_mat_parca_adi	site.urun_mat_part_name	site.urun_malzeme
1	GÖVDE	BODY	RG5
2	DİFÜZÖR	DIFFUSOR	RG5
3	NOZUL	NOZZLE	AISI316L
4	CONTA	GASKET	KLINGRIT
5	SAPLAMA	STUD	AISI316L
6	YAYLI RONDELA	SPRING LOCK	WASHER AISI316L
7	FİERLİ SOMUN	HEX. NYLON NUT	AISI316L
