site.urun_teknik_cizim
Hydraulic Control Levers
Hydraulic Control Lever
site.urun_kaynak
Metroend-Urun-Katalogu.pdf · site.urun_basili_sayfa
89
(PDF 92)
What it does
Hydraulic Control Levers
A hydraulic control lever is the control unit from which quick closing valves are triggered remotely. A single movement of the lever generates pressure in the hydraulic line and the connected valves close simultaneously. It is normally installed at a point that remains accessible in an emergency, such as the engine room exit, labelled with the list of valves it closes.
This is a general description of the product type; it has no counterpart in the source catalog and is awaiting company approval. The verified technical values for this product are only in the data plate above and in the dimension table.
Where it is used
Application areas
- 01 A hydraulic quick-closing lever is a control mechanism used to operate quick-closing valves remotely using hydraulic power.
Source: the “Application Areas” list on this product's catalog page.
site.urun_malzeme
site.urun_malzeme_ozellikleri
| site.urun_mat_no | site.urun_mat_parca_adi | site.urun_mat_part_name | site.urun_malzeme |
|---|---|---|---|
| 1 | GÖVDE | BODY | GGG40 |
| 2 | ŞASİ | CHASSIS | GGG40 |
| 3 | O-RING | O-RING | NBR |
| 4 | BURÇ | BUSH | MS58 |
| 5 | SİLİNDİR | CYLINDER | ST37 |
| 6 | KOL | LEVER | ST37 |
| 7 | CIVATA | BOLT | ST37 |
| 8 | TAPA | PLUG | AISI304 |
| 9 | YAĞ GÖSTERGESİ | OIL EYE | GLASS |
| 10 | SOMUN | NUT | ST37 |
| 11 | 78 | ||
| 12 | 200 | ||
| 13 | 48 36 | ||
| 14 | 156 |
